Connections for the markets of the future – SERTO stainless steel quick couplings
The Q5x series of SERTO quick couplings
provide compact, secure and leakage-free unions for demanding liquid and gas
circuits – ideal for applications in energy technology, pharma/biotech,
semiconductors and lasers.
Leakage-free
One-handed
operation
Coding
Hygienic
Stainless
steel
SERTO
quick couplings – the Q5x series at a glance
SERTO’s three series of Q50, Q51 and Q52
provide a flexible range of quick couplings for industrial and hygienically
sensitive applications. Securely coded, contamination-free and particularly
compact, each series meets the strictest requirements in terms of ease of use,
leak tightness and reliability.
Separate
products for each application
Our quick couplings can be configured
flexibly. Choose from various sealant materials such as FFKM, EPDM and VMQ.
Other options are also available on request.
We also offer separate cleaning and
lubrication products, such as:
OX
SI
FC – food-safe lubricant under Regulation (EG) 1935/2004
Applications
& markets – precise solutions for every environment
Energy
technology / IT
Couplings
for energy & IT – compact, reliable and can be uncoupled dry
In the energy and IT tech sectors, liquid
coolant systems are essential for regulating the performance of frequency
inverters, transformers, network components and server hardware.
SERTO stainless steel couplings can provide
leakage-free connections in the tightest of spaces and are hard-wearing,
low-maintenance and exceptionally reliable over extended use.
Typical
applications
- Coolant systems for frequency inverters, power inverters and
rectifiers
- Temperature control and refrigeration devices
Market segment: pharma & biotech
Hygienic,
safe and straightforward: coupling solutions for biotech
In pharmaceutical and biotechnological
processes, media and temperature control circuits must be connected quickly,
securely and without any contamination.
SERTO quick couplings meet these requirements thanks to their one-handed operation,
clear mechanical and colour coding and smooth, easy-to-clean surfaces –
ideal for use in clean rooms and sensitive environments.
Typical
applications:
- Temperature control circuits in reactors, fermenters, mixers
- Media supply for storage tanks and filling systems
Semiconductors / Lasers
Clean, coded and precise: couplings for the high-tech sector
In semiconductor and laser technology, the
requirements for cleanliness, process reliability and repeatability are
extremely strict.
SERTO stainless steel couplings offer
leakage-free, lubricant-free and mechanically coded connections for ultrapure
water, gas or solvent circuits that are reliable even under clean room
conditions.
Typical
applications:
- Etching processes using hydrogen or acids
- Ultrapure water and solvent circuits (isopropanol)
- Temperature regulation with CO₂ lasers
- Inert gas circuits (e.g. argon)
Produkt highlights
Q50/Q50+
– Safely coded for use in multiple circuits
✔ Mechanically
and colour coded ✔ Can be coded 8 times (Q50+) ✔ Unmistakable
Q51
– Universal industry coupling
✔ Compact ✔ One-handed use ✔ Saves space
Q52
– Hygienic & suitable for clean rooms
✔ Flat-faced ✔ Free from contamination ✔ Easy
to clean
Watch
now – new at SERTO: the TechTalk video series is launching!
In our TechTalks, we will be opening the
doors to our development department and giving you regular, exclusive insights
into new products, technological trends and innovative solutions from the world
of connection technology.
The first episode will deal with a topic
that is decisive in many applications: Quick couplings
Modular
& compatible: the SERTO modular system
SERTO quick couplings form part of a
well-designed modular system. A wide range of connections are available,
enabling the couplings to be incorporated easily and precisely into your
application:
- with internal or
external thread
- as bulkhead
connectors
- as threaded nipples
- or with hose nozzles
- more on request
Maximum flexibility – products from
different series can be used together.
SERTO Safety Q50 / Q50+
1. Nipples (Inox 1.4571)
2. Couplers (Inox 1.4571)
3. Sliding sleeves (Inox 1.4571)
4. Sealings (FKM (FDA)
5. Colour coding (FKM)
6. Compression spring (Inox 1.4310)
7. Return spring (Inox 1.4310)
8. Piston (Inox 1.4305)
9. Valves (Inox 1.4571)
Ergonomic
design
The couplers fit easily in your hand, making incorrect use virtually impossible
Intelligent
construction
Noise-free, even when vibrating
One-handed
operation
Coupling and uncoupling are smooth and
efficient
Smooth
surface
Easy to clean, hardly accumulates any dirt
Innovative
valve construction
Outstandingly high flow rate with low
pressure loss
FDA-compliant
materials
Broad range of applications, including in the food industry
SERTO Flow Q51
1. Couplers (Inox 1.4571)
2. Nipples (Inox 1.4571)
3. Sliding sleeves (Inox 1.4571)
4. Connections (Inox 1.4571)
5. Interior parts (Inox 1.4571)
6. Balls (Inox 1.4404)
7. Springs (Inox 1.4310)
8. Pistons (Inox 1.4571 / 1.4404)
9. FKM sealings (FDA)
Ergonomic
design
the couplers fit easily in your hand
One-handed
operation
coupling and uncoupling are smooth and
efficient
Flat-face technology
leakage-free coupling and uncoupling, easy
to clean
Smooth
surfaces
easy to clean, hardly accumulates any dirt
Innovative
valve construction
high flow rate with low pressure loss
FDA-compliant
materials
broad range of applications, including in
the food industry
SERTO Dry break Q52
1. Couplers (Inox 1.4571)
2. Nipples (Inox 1.4571)
3. Sliding sleeves (Inox 1.4571)
4. Connections (Inox 1.4571)
5. Interior parts (Inox 1.4571)
6. Balls (Inox 1.4404)
7. Springs (Inox 1.4571 / 1.4404)
8. FKM sealings (FDA)
Ergonomic
design
the couplers fit easily in your hand
One-handed
operation
coupling and uncoupling are smooth and
efficient
Flat-face
technology
leakage-free coupling and uncoupling, easy
to clean
Smooth
surfaces
easy to clean, hardly accumulates any dirt
Innovative
valve construction
high flow rate with low pressure loss
FDA-compliant
materials
broad range of applications, including in
the food industry
Note
on the availability of the Q52 series
Our new Q52 quick coupling series,
specially developed for applications with strict hygiene requirements, is
currently in the final product launch phase.
Available online from the beginning of
2026 onwards.
We would be happy to advise you as of now
of the technical details and potential uses of these valves, or provide you
with samples in advance.
